HPRWG2-35-2
Product Description
Condition of Use:
1. The ambient air temperatures within the range of -30 degreeto +40 degree;
2. The altitude above sea level not exceeding 1, 000m; (If the altitude is higher than 1, 000, it needs adjust. )
3. Frequency of the A. C. Power supply not less than 48Hz and not exceeding 52Hz;
4. Earthquake intensity not exceeding 7 degrees;
5. Maximum wind speed not exceeding 35m/s.
Technical Standard:
The technical performance of the products is in confirmed to IEC291, 282.
| Type | Rated voltage(KV) | Rated current(A) | Breaking current(KA) | Impulse voltage(KV) | Power-frequency withstand voltage(KV) | Leakage distance(MM) |
| HPRWG2-40.5 | 40.5 | 100 | 5 | 185 | 105 | 1440 |
The High Voltage Polymer Fuse for Transformer Overload Protection stands as a vital defense mechanism for modern power distribution networks. When handling the physical unit, the dense, smooth texture of the premium polymer housing immediately conveys a sense of rugged durability, meticulously crafted to resist the harshest environmental degradation. The metallic components gleam with a precision-engineered silver coating, indicating a strict attention to optimal conductivity and thermal management. Every sweeping curve of the shedding profile is aerodynamically and electrically optimized to shed water rapidly, preventing surface tracking and ensuring a pristine insulative barrier even after torrential downpours.
Beyond its striking physical build, this device acts as an uncompromising sentinel for your transformers. By instantly interrupting fault currents and overload conditions, it prevents catastrophic equipment failure, thereby eliminating exorbitant replacement costs and minimizing network downtime. The mechanical operation produces a crisp, decisive snap upon engagement—a sound that assures installation crews of a secure, locked-in connection. Whether deployed in highly corrosive coastal substations or arid, wind-swept desert grids, the superior craftsmanship guarantees that your electrical infrastructure remains active, stable, and profoundly protected against unpredictable power surges.
| Technical Parameters & Specifications | |
|---|---|
| Type | HPRWG2-40.5 |
| Rated voltage (KV) | 40.5 |
| Rated current (A) | 100 |
| Breaking current (KA) | 5 |
| Impulse voltage (KV) | 185 |
| Power-frequency withstand voltage (KV) | 105 |
| Leakage distance (MM) | 1440 |
| Condition of Use | |
| Ambient Air Temperature | Within the range of -30 degree to +40 degree |
| Altitude | Not exceeding 1, 000m; (If the altitude is higher than 1, 000, it needs adjust.) |
| Frequency of A.C. Power Supply | Not less than 48Hz and not exceeding 52Hz |
| Earthquake Intensity | Not exceeding 7 degrees |
| Maximum Wind Speed | Not exceeding 35m/s |
| Technical Standard | |
| The technical performance of the products is in confirmed to IEC291, 282. | |
| Service & Support Details | |
| Samples providing? | We are providing the samples for free, but need pay for the freight charge. |
| EPC material design and provide in lot? | Yes, we are supplying for LV and MV EPC material in lot many years, and have strong design team. |
| OEM available? | Yes, we are providing the anchor clamp as custom requirement. |
| Complete documents for tender? | Yes, whole set documents ready for submit. |
